Support interference signal and deception signal detection, and output alarm information
Can receive multiple time references and has the ability to measure and monitor time references
Equipped with LCD time display (year/month/day/day/hour/minute/second) and parameter configuration function
Built in high-performance frequency source (rubidium clock or crystal oscillator) with automatic frequency calibration function
Multiple time codes, pulses, frequencies, and other signals can be selected for output
Adapt to user needs and provide various forms of products 1U/2U/3U
Equipped with fault alarm prompt function and capable of monitoring device status through serial port/network
Supports multicast and unicast modes
Working mode: Master or Slave mode, One step or Two step mode
Support P2P and E2E latency mechanisms
Can choose rubidium clock or constant temperature crystal oscillator
NTP response times:>140000 times/second
Built in high-performance rubidium clock and low phase noise constant temperature crystal oscillator
Support external time-frequency signal measurement and reporting function
Support high-precision time and frequency signal output
Built in WEB management platform, convenient for viewing device status and setting parameters
Optional configuration with built-in battery, convenient for moving and working with power on
Optional high-precision time synchronization between multiple devices, with synchronization accuracy better than 2ns
Output sine wave
Short term stability can reach<6E-13/S
Accuracy: 25ns relative to Coordinated Universal Time
Phase noise<-110dBc/ Hz@1Hz (Optional)
Supports 100MHz output (optional)
Output sine wave
Short term stability can reach<3E-13/s
phase noise <-115dBc/ Hz@1Hz
Optional 10/100MHz output
Integrated device for positioning, orientation, and timing
Built in full frequency, full system satellite receiver
Can support BeiDou(COMPASS) 3rd generation and military code requirements
Flexible configuration of output channels
Support forwarding and generative deception, interference signal detection, and alarm output
Support prevention of forwarded, generated, and invasive signal spoofing
Optional Rubidium clock or constant temperature Crystal shaker as navigation frequency source
Output normal satellite signal function under deception and interference conditions
Adjustable output signal strength (power)
Support remote WEB monitoring of device working status and setting of working parameters
Tested by the Experimental Verification Center of State Grid Electric Power Research Institute
Supports full height or half height sizes
PTP supports electrical or optical port modes
Capable of high-precision punctuality
Interrupt frequency 1-1000Hz configurable
Support SNMP protocol and WEB monitoring
The driver supports commonly used operating systems such as Windows, Linux, QNX, and rtLinux
100% national production design
Small size, low power consumption
Can receive signals from satellites, B-code, 1PPS+TOD, etc. to tame Crystal shaker
Can output signals such as B (DC), 1PPS, TOD time code, NTP, PTP, etc
Can be configured to output 10MHz or other specific frequency signals
Capable of high-precision punctuality
