Phase micro-leap resolution: 2π/2^32
Phase noise: <-160dBc/Hz@1kHz
Time micro-leap resolution: 0.024fs
Frequency stability: ≤6E-14/s
Frequency micro-leap resolution: 1E-19
Supports mixed inputs of 5MHz and 10MHz, with outputs of 5/10MHz
Frequency stability better than 5E-13/s
Phase noise of 10MHz output is <-110dBc/Hz at 1Hz offset
Phase change before and after switching is ≤0.3ns
Suitable for clock arrays, primary/backup systems, and other fields that require high continuity of timing signals.
Input 10MHz, output 10MHz
Frequency stability better than 3E-13/s
10MHz output phase noise<-115dBc/ Hz@1HZ
Input and output frequencies can be customized
Application areas: phase noise enhancement for hydrogen, cesium, rubidium atomic clocks, clock signal recovery and purification, radar, etc
Up to 32 output channels can be selected, with a wide frequency
working range, supporting 1Hz-10MHz, and compatible with IRIG-B(DC) code.
It has an extremely short rise and fall time.
Short channel delay and low timing jitter.
Supports wide level input, with output as TTL signal, and a peak-to-peak value of 2.5Vpp.
Supports dual input channels.
Input: 1-120MHz Output Frequency: 1-120MHz
Module/Standard Chassis
Relative Phase Jitter between Channels: <3fs@1s
Frequency Stability: ≤5E-15/s
Phase Noise: ≤-140dBc/Hz@1Hz
Chassis version supports dual input channels
